Split Cable Gland Singapore

Simply pass the cable termination through the ltcg body apply split gland to the cable and insert the gland cable assembly into the ltcg fingers.

Split cable gland singapore. The purpose of a cable gland is to seal the cable and retain it in the electrical equipment that it is attached to. Pflitsch brought the first completely splittable plastic single cable gland to the market in the form of the uni split gland. This product allows preassembled cable to be fed through a hole or the replacement of old or defective cable glands without having to interfere with the existing cable installation or switch off the affected machine. Then tighten the sealing nut to achieve a liquid tight seal.

As a cord grip cable strain relief cable connector or cable fitting is a device designed to attach and secure the end of an electrical cable to the equipment. A cable gland more often known in the u s. A cable gland is a device which attach and secure the end of an electrical cable to the equipment. It should maintain the ingress protection rating of the enclosures keeping out dust and moisture but it should also prevent the.

A cable gland provides strain relief and connects by a means suitable for the type and description of cable for which it is designed including provision for making electrical connection to. E g rj45 cable with cat5e termination. Uni split gland splittable cable gland. Uni flange splittable cable entry.

The uni split gland is a fully split cable gland. The cable gland body pressure screw and lock nut each consist of two halves and the sealing inserts are slit at the side so that preassembled cables can be placed in them. Cmp products singapore office is our stock capital for asia and plays a significant role in marine and ship building projects at the heart of activity in asia. We provide sustainable solutions that help our customers effectively manage electrical hydraulic and mechanical power more safely more efficiently and more reliably.

The new split cable gland kvt er provides high certified ingress protection ratings ip65 ip66 ip67 ip68 ul type 12 4x due to an injected gasket and it provides strain relief acc. During servicing or retrofitting with pre assembled cable harnesses cables with diameters from 2 to 35 mm can quickly and safely be guided into the switchgear cabinet or housing and then sealed to ip66. Split glands are designed for application to the cable after the cable has passed through the ltcg. Split cable gland features split cable gland body pressure screw and counter nut used for cables with connectors attached the polycarbonate split gland is available in sizes m25 and m32 m20 available on request over 100 different sealing inserts available for cable cross sections of 2 0 mm to 20 5 mm ip 67 protection.

Conta clip can now offer the kds kv split cable glands from m20 to m63 for cables with or without connectors. Eaton s mission is to improve the quality of life and the environment through the use of power management technologies and services. 21 toh guan road east 09 03 toh guan centre singapore 608609.
